Name: Flash Sale 👏 American Flow Control 2500 Series 8 in. Flanged Ductile Iron OS&Y Resilient Wedge Gate Valve ✔️ | Cheap American Flow Control Store
SKU: 4273368
Price: 98.99 USD
Availability: InStock

Sale!

Original price was: $199.79.Current price is: $98.99.

SKU: 4273368 Categories: AWWA Valves, Resilient Wedge Gate Valves Tag: Ductile Iron, Stainless Steel

Quality Products, Quality Service
Fast reliable delivery options
Buy quality, buy with us.
The quality you expect, the service you deserve.

All ductile iron construction

Complies with ANSI/AWWA C515

UL listed and FM approved

Certified to NSF/ANSI/CAN 61 and NSF/ANSI/CAN 372

250 psig AWWA UL and FM pressure rating

Fusion-bonded epoxy coating complies with ANSI/AWWA C550

Thrust washers

Smooth waterway design

100% leak-tight closure

ANSI Specifications	ANSI 372, ANSI 61, ANSI A21.10, ANSI B18.2.1, ANSI C110, ANSI C515, ANSI C550
NSF Certified	Yes
Waterworks Application	Water
Valve Type	Resilient Wedge Gate Valve
Valve Stem	Non-rising
Valve Size	8 in
Valve Seat Material	Metal
Valve Port Opening	Valve Stem
Valve Operator	Operating Nut
Valve Disc Material	Ductile Iron
Valve Bonnet Type	Bolted
UL Listed	Yes
Recommended Valve Application	Drinking Water, Fire Protection, Irrigation, Sewage
Pressure Class	125#
NSF Specifications	NSF 372, NSF 61
Maximum Pressure	500 psig
ASME Specifications	ASME B16.1 Class 125
Material	Ductile Iron, Stainless Steel
MSS Specifications	MSS SP-45
Length	11-1/2 in
High Pressure	250
FM Approved	Yes
End Connections	Flanged
End Connection 2	Flanged
End Connection 1	Flanged
Ductile Iron Pipe Type	Ductile Iron Flanged Pipe
Collection	2500 Series
Coating	Fusion Bonded Epoxy
AWWA Specifications	AWWA A-21.10, AWWA C-110, AWWA C-515, AWWA C-550
ASTM Specifications	ASTM A-536, ASTM D-1785, ASTM D-2000, ASTM D-2241
Weight	205
