Name: Brand new 🛒 American Flow Control 3500 Series 12 in. Mechanical Joint Ductile Iron Open Left Resilient Wedge Gate Valve ⭐ | Cheap American Flow Control Store
SKU: 5162221
Price: 94.99 USD
Availability: InStock

Sale!

Original price was: $270.40.Current price is: $94.99.

SKU: 5162221 Categories: AWWA Valves, Resilient Wedge Gate Valves Tag: Ductile Iron

Quality Products, Quality Service
Fast reliable delivery options
Buy quality, buy with us.
The quality you expect, the service you deserve.

Fully complies with ANSI/AWWA C515 and is rated at 350 psig

UL listed and FM approved at 350 psig, in applicable configurations

Smooth waterway design

100% leak-tight closure

Triple O-ring stem seals

Thrust washers above and below thrust collar to provide for easier operation

All ductile iron construction

Fusion-bonded epoxy coating on the interior and exterior

O-ring style gaskets

ANSI Specifications	ANSI 372, ANSI 61, ANSI A21.11, ANSI B18.2.1, ANSI C111, ANSI C515, ANSI C550
NSF Certified	Yes
Waterworks Application	Water
Valve Type	Resilient Wedge Gate Valve
Valve Stem	Non-rising
Valve Size	12 in
Valve Seat Material	Metal
Valve Port Opening	Valve Stem
Valve Operator	Operating Nut
Valve Disc Material	Ductile Iron
Valve Bonnet Type	Bolted
Valve Body Style	Open Left
UL Listed	Yes
Recommended Valve Application	Drinking Water, Fire Protection, Sewage
NSF Specifications	NSF 372, NSF 61
Maximum Pressure	700 psig
ASME Specifications	ASME B16.1, ASME B16.4
Material	Ductile Iron
MSS Specifications	MSS SP-113, MSS SP-45
Length	13-1/2 in
High Pressure	350
FM Approved	Yes
End Connections	Mechanical Joint
End Connection 2	Mechanical Joint
End Connection 1	Mechanical Joint
Ductile Iron Pipe Type	Ductile Iron Mechanical Joint Pipe
Collection	3500 Series
Coating	Fusion Bonded Epoxy
AWWA Specifications	AWWA A-21.11, AWWA C-111, AWWA C-515, AWWA C-550
ASTM Specifications	ASTM A-536, ASTM B-763
Weight	371
