Name: Best Pirce 👏 American Flow Control Alpha™ 2500 Series 10 in. Restrained Joint Ductile Iron 316 Bolts Open Left Resilient Wedge Gate Valve 🧨 | Cheap American Flow Control Store
SKU: 7239527
Price: 79.32 USD
Availability: InStock

Sale!

Best Pirce 👏 American Flow Control Alpha™ 2500 Series 10 in. Restrained Joint Ductile Iron 316 Bolts Open Left Resilient Wedge Gate Valve 🧨

Original price was: $113.31.Current price is: $79.32.

SKU: 7239527 Categories: AWWA Valves, Resilient Wedge Gate Valves Tag: Ductile Iron

Quality Products, Quality Service
Fast reliable delivery options
Buy quality, buy with us.
The quality you expect, the service you deserve.

ANSI Specifications	ANSI A21.10, ANSI B18.2.1, ANSI C110, ANSI C515, ANSI C550
Maximum Pressure	250 psig
Valve Type	Resilient Wedge Gate Valve
Valve Stem	Non-rising
Valve Size	10 in
Valve Seat Material	Metal
Valve Port Opening	Valve Stem
Valve Operator	Operating Nut
Valve Disc Material	Ductile Iron
Valve Bonnet Type	Bolted
Valve Body Style	Open Left
UL Listed	Yes
NSF Specifications	NSF 372, NSF 61
NSF Certified	Yes
Material	Ductile Iron
ASME Specifications	ASME B16.1 Class 125, ASME B16.4
MSS Specifications	MSS SP-113, MSS SP-45
Length	17-17/50 in
FM Approved	Yes
End Connections	Restraint Joint
End Connection 2	Restraint Joint
End Connection 1	Restraint Joint
Ductile Iron Pipe Type	Ductile Iron Restrained Joint Pipe
Collection	Alpha™ 2500 Series
Coating	Fusion Bonded Epoxy
Application	Backflow Preventer, Fire, Irrigation, Potable Water, Sewage
AWWA Specifications	AWWA A-21.11, AWWA C-111, AWWA C-515, AWWA C-550
ASTM Specifications	ASTM A-536, ASTM D-1785, ASTM D-2000, ASTM D-2241
Waterworks Application	Water
